Image Control	MOBOTIX M1M V1.7.0.9
Home MultiView About... Help PC Recorder Event Player Image Control Event Control Exposure Control QuickInstall Admin		Attribute  Value    Explanation   Camera Select right left both factory default: right camera sensor  Image Size 320x240 640x480 factory default: 320x240  Frames per Second 1 2 3 4 6 12 speed of jpeg conversion use low values to improve cameras event control  Automatic Contrast  auto turn on/off  Brightness [-10..+10] -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 factory default: 0  Backlight Correction [-10..+10] -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 factory default: 4  Color Saturation [-10..+10] -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 factory default: 5  Blue Balance [-10..+10] -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 factory default: 0  Red Balance [-10..+10] -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 factory default: 0  Sharpness [0..10] 0 1 2 3 4 5 6 7 8 9 10 factory default: 4 (sharpen decreases framerate)  JPEG Quality 10% 20% 30% 40% 50% 60% 70% 80% 90% factory default: 80%  Text Display disable transparent background black background best with transparent background  Display Error Messages disable enable enable errors to display messages onto image  Date and Time off Date & Time Time Time & Milliseconds Date Date long select format of date and time  Comment This text will be shown in every picture. There are special characters available.  Mirroring Image don´t mirror vertical horizontal both vertical mirroring takes a lot more time  Rotate 0° 180° currently only 180° supported

---
