Event Parameter  Explanation
Passive Infrared Detector (PI) Motion detection by an infrared sensor.
  Triggerlevel [0-100%]
Microphone (MI) (not supported) Noise detection by internal microphone.
  Triggerlevel [0-100%]
Video Motion Window (VM) Motion detection by digital image analysis.
  x, y, sizex, sizey, sensitivity[0..99%], area[0..99%]
Origin: lower left corner
Signal Input (SI) This event is triggered through an external signal.
  closed (low) open (high) Signal level to trigger on.
Buttons (BT) Trigger event by pressing button(s) on front panel.
  Select button(s) to trigger on.
IR-Remote Control (IR) Trigger an event by signals from any IR-remote control.
  IR-Code to receive for an event.
Periodic Event (PE) This event is triggers periodically every x seconds.
  interval [0..86400s]
Time Task (TT) Trigger this event via Time Tasks.
User Click (UC) This event triggers by clicking the button on the Web-Sites.
IP-Receive (RC) (not supported) Event on receiving a message over TCP/IP.
  TCP port to listen to.
  Defines a message to wait for. Leave empty to trigger on any message.

Action Parameter  Explanation
Signal Out Action (SO) Switch signal output to high for chosen time.
Email Action (EM) Send image by email.
File Transfer Action (FT) Transfer image to remote host using file transfer protocol.
Local Store Action (ST) Save image to ramdisk. You can view the images saved on the camera with Event Viewer.
Backup (BU) Store ramdisk to permanent memory (every 15 minutes). You can also store manually.
Ringbuffer Enable overwriting of images on ramdisk.
Event Story Additional images to save before every event.
  Additional images to save after every event.
Interval Time interval for image series in ms. [0..600.000 msec]
Motion Window Border Defines the appearance of the motion window border.
IP-Notify (IP) (not supported) Send a message to an IP-address.
  Receivers IP-address and port.
Separate IP-address from port with colon.
  Defines the message.

General Settings   Explanation
Minimum Event Duration (D) Length of time [0..100s] that an event must last to release an action.
Invert Event (I) Select which event state initiates an action.
Action Delay Delay period between event and action[0..100s]
Event Deadtime Event timeout [0..100s] while detection is suspended.
Event Symbols Show event symbols.
Use Symbols II with many activated events.
